NOBILY Roller Shutter Timer ZS1
€27.90*
% €32.90* (15.2% saved)Available, delivery time: 1-3 days
Elegant in design and optimally integrable ...
The ZS1 from Nobily is a professional roller shutter timer, which can be smartly and easily integrated into the switch range. Due to its compact size of 50x50mm and the harmony of the design with the programs of leading switch manufacturers, our ZS1 is ideal for every living area.
- Professional roller shutter timer ZS1
- Reliable and elegant in design
- Made in Germany
- 2 year guarantee
- Available exclusively from NOBILY
- Can be integrated into all common branded switch programs such as Merten, Busch-Jaeger ...
Product highlights
- Daily program
- Weekly program
- Manual operation (inching operation)
- Automatic mode (self-holding)
- Security vacation switching (random generator)
- Memory function (express programming)
- Power reserve (± 0.45 h)
- adaptable to various branded switch programs with 50 x 50 mm intermediate frames
- Surface ultra white
- incl. Flush frame
| Einbauart: | Unterputz |
|---|---|
| Steuerung 50x50 mm: | Ja |
| Steuerungsart: | Kabelgebunden |
| Steuerungsfunktionen: | Automatikbetrieb, Memory Funktion, Security Urlaubsschaltung, Tagesprogramm, Wochenprogramm |
| Name: | timer | timer | timer | timer | timer | timer |
| Name: | ZS1 | ZS1 + surface frame | ZS1 for Gira | ZS1 for Merten | ZS1 for Busch-Jaeger | ZS1 for Jung |
| Manual operation: | Yes | Yes | Yes | Yes | Yes | Yes |
| Watch type: | Wired | Wired | Wired | Wired | Wired | Wired |
| Automatic mode: | Yes | Yes | Yes | Yes | Yes | Yes |
| Daily program: | Yes | Yes | Yes | Yes | Yes | Yes |
| Weekly program: | Yes | Yes | Yes | Yes | Yes | Yes |
| preset opening and closing times: | Yes | Yes | Yes | Yes | Yes | Yes |
| Security vacation switching: | Yes | Yes | Yes | Yes | Yes | Yes |
| Memory function: | Yes | Yes | Yes | Yes | Yes | Yes |
| Astro Cosmic Function: | No | No | No | No | No | No |
| Sun sensor can be connected: | No | No | No | No | No | No |
| Indication via display: | Yes | Yes | Yes | Yes | Yes | Yes |
| Color: | Ultra white | Ultra white | Ultra white | Ultra white | Ultra white | Ultra white |
| Power reserve: | ± 0.45 h | ± 0.45 h | ± 0.45 h | ± 0.45 h | ± 0.45 h | ± 0.45 h |
| Summer / winter time change: | Yes | Yes | Yes | Yes | Yes | Yes |
| suitable as roller shutter control: | Yes | Yes | Yes | Yes | Yes | Yes |
| suitable as blind control: | Yes | Yes | Yes | Yes | Yes | Yes |
| Concealed installation: | Yes | Yes | Yes | Yes | Yes | Yes |
| usable in the surface-mounted housing: | Yes | Yes | Yes | Yes | Yes | Yes |
| Runtime drive: | approx. 3 min. | approx. 3 min. | approx. 3 min. | approx. 3 min. | approx. 3 min. | approx. 3 min. |
| Switching contact load capacity_Relais: | cos phi > 0.8 / 3A / 230V / 50Hz | cos phi > 0.8 / 3A / 230V / 50Hz | cos phi > 0.8 / 3A / 230V / 50Hz | cos phi > 0.8 / 3A / 230V / 50Hz | cos phi > 0.8 / 3A / 230V / 50Hz | cos phi > 0.8 / 3A / 230V / 50Hz |
| Pluggable housing: | Yes | Yes | Yes | Yes | Yes | Yes |
| Dimensions WHD mm without frame: | 50 x 50 x 40 mm | 50 x 50 x 40 mm | 50 x 50 x 40 mm | 50 x 50 x 40 mm | 50 x 50 x 40 mm | 50 x 50 x 40 mm |
| Dimensions WHD mm with frame: | 80 x 80 x 40 mm | 80 x 80 x 40 mm | 80 x 80 x 40 mm | 80 x 80 x 40 mm | 80 x 80 x 40 mm | 80 x 80 x 40 mm |
| Environmental conditions: | dry living spaces | dry living spaces | dry living spaces | dry living spaces | dry living spaces | dry living spaces |
| Single PU: | Yes | Yes | Yes | Yes | Yes | Yes |
| Guarantee: | 2 years | 2 years | 2 years | 2 years | 2 years | 2 years |
| Article No. : | 1221101000007 | 1221101100007 | 1221101400007 | 1221101600007 | 1221101300007 | 1221101500007 |
Login
30 October 2018 08:33
Hat alle wesentlichen Funktionen
Hat alle wesentlichen Funktionen (im Automatikbetrieb), die wir wahrscheinlich nicht alle nutzen werden. Schickes Design und gute Verarbeitung. Sehr gutes Preis-/Leistungsverhältnis. Mit dazubestelltem Zwischenrahmen konnten wir die Bedienheit in unser Jung AS Schalterprogramm integrieren.
22 May 2023 08:56
Super Zeitschaltuhr ZS1
Ich besitze diese Schaltzeituhr auch bereits seit mehrere Jahre. Funktioniert tadellos und zuverlässig. Im Urlaub stelle ich sie auf den Zufallsmodus. Bin voll zufrieden mit diesen Einheiten ZS1.
